Best 4G LTE Indoor Antenna PCB Trace Antenna

75x5mm Best 4G LTE Indoor Antenna PCB Trace Antenna Manufacturer - C&T RF Antennas Inc

Best 4G LTE Indoor Antenna Manufacturer

C&T RF Antennas Inc. is the best 4G LTE indoor antenna manufacturer in China. We provide the 4G antenna with many antenna types such as PCB antenna, flexible PCB antenna, rubber duck antenna, fiberglass antenna, through-hole mount antenna, etc.

Contact the C&T RF sales team for more Best 4G LTE Indoor Antenna details such as antenna datasheet, antenna price, and antenna inventory.

Description

What is the Best 4G LTE Indoor Antenna PCB Trace Antenna?

The Best 4G LTE Indoor Antenna PCB Trace Antenna CTRF-ANTENNA-PCB-7027-7505-IPEX model is an indoor 4G antenna with a full frequency range from 698MHz (excluding band B71) to 2700MHz suited for ISM/SCADA/Utilities, IoT/NB-IoT/LoRa, 4G LTE/LTE-IoT applications.

Best 4G LTE Indoor Antenna PCB Trace Antenna Item Model CTRF-ANTENNA-PCB-7027-7505-UFL100 is Lora | 3G | 4G | LTE | NB-IoT | PCS | GSM antenna indoor PCB trace antenna.

The Best 4G LTE Indoor Antenna PCB Trace Antenna Is manufactured by C&T RF Antennas Inc., a professional RF antenna manufacturer in China.

C&T RF Antennas Inc provides internal & external antennas with antenna radio frequencies such as NFC169MHz230MHz315MHz433MHz868MHz915MHzVHF&UHFLoraNB-IoTADS-BGSMGNSS, GPRS, 1.2 GHz, 1.4 GHz, 1.8 GHz, Wi-Fi 2.4 GHz, 5.8 GHz, Cellular 2G, 3G, 3.5 GHz, 4G LTEGPS5G NR, 6G, etc.

C&T RF Antennas Inc. provides RF antennae with Omni & Directional antenna types such as Dipole AntennasWhip AntennasMarine AntennasRouter AntennasMIMO AntennasCombo AntennasPCB AntennasFPC AntennasSpring AntennasMagnetic AntennasSector AntennasYagi Antennas, and Accessories, etc, for IoT & M2M industries.

Contact us for the Best 4G LTE Indoor Antenna PCB Trace Antenna for more details such as Best 4G LTE Indoor Antenna datasheet, Best 4G LTE Indoor Antenna pricing, Best 4G LTE Indoor Antenna inventory, or other Best 4G LTE Indoor Antenna PCB Antenna types.



 Indoor Antenna LTE 4G PCB Antenna Specifications:

 Indoor Antenna LTE 4G PCB Antenna Electrical Specifications

RF Antenna Type Built-in PCB Antenna
Model CTRF-ANTENNA-PCB-7027-7505-IPEX
Frequency 698-960MHz, 1710-2700MHz
Gain 3dBi/5dBi
VSWR ≤2.5
Impedance 50 Ω
Polarization Vertical/Linear
Cable Type RG1.13
Connector U.FL/IPEX
Cable Length 100mm
Lightning Protection DC-Ground

 Indoor Antenna LTE 4G PCB Antenna Mechanical Specifications

PCB Board Dimension 75*5mm
Weight Approx. 4g
Material PCB + RG Cable + U.FL connector
Operation Temperature -40˚C ~ +65˚C
Storage Temperature -40˚C ~ +70˚C
Color Green
Antenna Design Dipole Antenna
Mounting Connector/Peel-and-stick
Safety Emission and other RoHS Compliant
Applications ISM/SCADA/Utilities, IoT/M2M/NB-IoT/LoRa, 2G 3G 4G LTE/LTE-IoT, GSM GPRS UMTS, etc.

Best 4G LTE Indoor Antenna PCB Antenna Features

PCB Antenna 3M type or other adhesive sticker mount C&T RF Antennas Inc
PCB Antenna 3M type or other adhesive sticker mount C&T RF Antennas Inc



Well soldered on PCB board antenna Manufacturer C&T RF Antennas Inc
Well soldered on PCB board antenna Manufacturer C&T RF Antennas Inc





IPEX UFL MHF antenna connectors or opening end C&T RF Antennas Inc
IPEX UFL MHF antenna connectors or opening end C&T RF Antennas Inc





RG low loss cable antenna extension antenna extender - C&T RF Antennas Inc

RG low-loss cable antenna extension antenna extender – C&T RF Antennas Inc





Best 4G LTE Indoor Antenna Applications

Wireless antenna RF Antenna Applications-CT-RF-Antennas-Inc
Wireless antenna RF Antenna Applications-CT-RF-Antennas-Inc



What is a Circuit Board PCB Antenna

PCB is an important electronic component, support for electronic components, and a carrier for the electrical connection of electronic components. Because it is made by electronic printing, it is called a printed circuit board.

After electronic equipment adopts printed boards, due to the consistency of similar printed boards, manual wiring errors can be avoided, and electronic components can be automatically inserted or mounted, automatic soldering, and automatic detection, ensuring the quality of electronic equipment, Improving labor productivity, reduce costs, and facilitate maintenance.

Printed boards have developed from single-layer to double-sided, multi-layer, and flexible, and still maintain their respective development trends.

Due to the continuous development of high precision, high density, and high reliability, continuous reduction in size, cost reduction, and performance improvement, the printed board will still maintain a strong vitality in the future development of electronic equipment.

The circuit board PCB antenna is the antenna that receives or sends wireless signals and is made on the circuit board through the copper-clad etching process.

This kind of antenna is integrated with related electronic components and used in the form of a module. Its advantage is high integration, which can compress the volume and reduce the cost, its disadvantage is that the communication distance is limited and the sensitivity is low, but in a short distance, remote control and Communication and other aspects are still widely used.



Additional information

Frequency

698-960MHz, 1710-2700MHz

Gain

3/5dBi

Cable

RG 1.13

Mounting

3M sticker

Connector

IPEX IPX MHF UFL
