Embedded 4G Antenna For Router Flex PCB Antenna

34x12mm Embedded 4G Antenna For Router Flex PCB Antenna Design - C&T RF Antennas Inc

4G Antenna For Router Manufacturer

C&T RF Antennas Inc is the Embedded 4G Antenna For Router Flex PCB Antenna Manufacturer in China, we provide the 4G LTE Antenna with internal & external antenna types for your best choice.

Contact the C&T RF team for more Embedded 4G Antenna For Router Flex PCB Antenna details.

Description

What is an Embedded 4G Antenna For Router Flex PCB Antenna?

The Embedded 4G Antenna For Router Flex PCB Antenna CTRF-ANTENNA-FPC-7027-3412-UFL120 is a built-in antenna 2G 3G 4G indoor antenna manufactured by C&T RF Antennas Inc for the Lora, GSM, NB-IoT, UMTS, LTE wireless network applications.

The internal 3G 4G Antenna Flexible PCB Antenna is a 34x12mm flexible printed circuit trace board antenna, 3dBi gain, 120mm length antenna cable extension, flexible antenna for GSM NB-IoT LTE 3G 4G networks.

Understanding 4G

To learn 4G, we need to know what 4G is, 4G is the fourth-generation mobile communication system.

The fourth-generation mobile communication system can be referred to as broadband access and distributed network, and its network architecture will be an all-IP network architecture.

4G networks are supported by a number of key technologies, including Orthogonal Frequency Division Multiplexing (OFDM)

The 4G network is supported by many key technologies, including Orthogonal Frequency Division Multiplexing (OFDM), multi-carrier modulation, Adaptive Modulation and Coding (AMC), MIMO, smart antenna technologies, IP-based core networks, software radio technologies, and Network optimization and security, etc.

In addition, gateways are needed to establish network interconnection with traditional networks, so 4G will be a complex multi-protocol network.



The Embedded 4G Antenna For Router Flex PCB Antenna is supplied by C&T RF Antennas Inc, the leading indoor-outdoor 4G LTE antenna manufacturer in China.

We provide the IoT M2M antennas with other antenna radio frequencies such as 169MHz230MHz315MHz433MHz868MHz915MHzLoraNB-IoTGSM, Wifi 2.4GHz, 5.8GHz, 2G 3G 4G LTEGPS5G NR, etc.

C&T RF Antennas Inc provides the 4G LTE antenna with many antenna types such as Dipole AntennasWhip AntennasMarine AntennasRouter AntennasMIMO AntennasPCB AntennasFPC AntennasSpring Antennas, etc, for IoT & M2M industries.

The Embedded 4G Antenna For Router Flex PCB Antenna is available at C&T RF Antennas Inc, Contact us for the 4G Antenna For Router antenna datasheet, 4G Antenna For Router antenna pricing, and 4G Antenna For Router antenna inventory, or other GSM 3G 4G LTE Antenna types.

Embedded 4G Antenna For Router Flex PCB Antenna Specifications

Embedded 4G Antenna For Router Flex PCB Antenna Electronical Specifications

RF Antenna Type Flexible PCB/FPC Antenna
Model CTRF-ANTENNA-FPC-7027-3412-UFL120
Frequency 698-960MHz, 1710-2700MHz
Gain 2/4dBi
VSWR ≤2.0
Impedance 50 Ω
Polarization Omnidirectional
Cable RG1.13mm
Cable Length 120mm
Connector U.FL/IPEX/MHF
Lightning Protection DC Ground

Embedded 4G Antenna For Router Flex PCB Antenna Mechanical Specifications

Dimension 34x12mm
Weight Approx. 4g
Material Flexible PCB/FPC
Operation Temperature -40˚C ~ +85˚C
Storage Temperature -40˚C ~ +80˚C
Color Black
Antenna Form Omni Dipole
Mounting Sticker/Connector
Safety Emission and other RoHS Compliant
Applications Public Safety/LMR/P25/TETRA, ISM/SCADA/Utilities, RFID, IoT/NB-IoT/LoRa/2G/3G/4G, GSM/GPRS/LTE

Embedded 4G Antenna For Router Flex PCB Antenna Features

Built-in Antenna Flexible Antenna Flex PCB Antenna FPC Antenna Features - C&T RF Antennas Inc Antenna Company
Built-in Antenna Flexible Antenna Flex PCB Antenna FPC Antenna Features – C&T RF Antennas Inc Antenna Company



Built-in Antenna Flexible Antenna Flex PCB Antenna Features - C&T RF Antennas Inc Antenna Supplier
Built-in Antenna Flexible Antenna Flex PCB Antenna Features – C&T RF Antennas Inc Antenna Supplier



RG cable with low loss antenna extension antenna extender - C&T RF Antennas Inc Antenna Manufacturer
RG cable with low loss antenna extension antenna extender – C&T RF Antennas Inc Antenna Manufacturer



IPEX Antenna UFL Antenna MHF Antenna connector or opening end for solder - C&T RF Antennas Inc
IPEX Antenna UFL Antenna MHF Antenna connector or opening end for solder – C&T RF Antennas Inc



3G 4G LTE Antenna Applications

Indoor-Outdoor Antenna RF Wireless Antenna Applications C&T RF Antennas Inc
Indoor-Outdoor Antenna RF Wireless Antenna Applications C&T RF Antennas Inc
