High Gain 5G New Radio PCB Antenna

113x16mm High Gain 5G New Radio PCB Antenna Manufacturer - C&T RF Antennas Inc

5G New Radio PCB Antenna Design

C&T RF Antennas Inc is the 5G New Radio PCB Antenna Design & Antenna Manufacturer in China, we provide the PCB 5G New Radio Antenna and flexible PCB 5G New Radio Antenna for your best choice.

Contact the C&T RF team for more High Gain 5G New Radio Antenna details.

Description

What is a High Gain 5G New Radio PCB Antenna?

The 5G New Radio PCB Antenna CTRF-ANTENNA-PCB-60600-11316-IPEX is an Omni dipole PCB antenna with a 10dBi high-gain antenna 5G NR PCB antenna manufactured by C&T RF Antennas Inc, the indoor-outdoor NR 5G New Radio antenna manufacturer in China.

The High Gain 5G New Radio PCB Antenna has a 113x16mm printed circuit board size, high-gain 10dBi antenna, and 120mm cable Ipex u. FL connector, adhesive mount, internal 5G New Radio antenna for the New 5G wireless communication industry.

Main 5G New Radio technologies:

1. Massive MIMO

2. Millimeter-wave communication

3. The filter bank multi-carrier modulation technology typically includes FBMC/UF-OFDM/GFDM/BFDM, etc.

4. Dense networking and heterogeneous networks increase cell density, thereby increasing system capacity and spectrum reuse rate.

5. D2D (device to device), an in-vehicle network that enhances the user’s service quality and user experience.

6. Software Defined Network SDN

7. Cognitive Radio Network

8. Visible light communication

9. Green communication is resource-saving and maximizes resource utilization.

10. The ultimate structure may be user-centric, weaken the concept of community, adopt cloud technology, distributed computing, etc., multiple technologies coexist, achieve low complexity, service diversity, small communication delay, and high resource utilization. At the same time, the user service quality and user experience are improved.

High Gain 5G New Radio PCB Antenna is supplied by C&T RF Antennas Inc, the leading PCB antenna manufacturer in China.

We provide the RF antennas with other antenna radio frequencies such as 169MHz230MHz315MHz433MHz868MHz915MHzLoraVHF&UHFNB-IoTGSMWifi 2.4GHz, 5.8GHz, 2G 3G 4G LTEGPS5G NRUWB, etc.

C&T RF Antennas Inc provides the wireless antenna with many antenna types such as Dipole AntennasWhip AntennasMarine AntennasRouter AntennasMIMO AntennasPCB AntennasFPC AntennasSpring Antennas, etc.

The High Gain 5G New Radio PCB Antenna is available at C&T RF Antennas Inc, Contact us for the High Gain 5G New Radio PCB Antenna datasheet, High Gain 5G New Radio PCB Antenna pricing, and inventory on the High Gain 5G New Radio PCB Antenna.

High Gain 5G New Radio PCB Antenna Specifications

High Gain 5G New Radio PCB Antenna Electronical Specifications

RF Antenna Type PCB Antenna
Model CTRF-ANTENNA-PCB-60600-11316-IPEX
Frequency 600-6000MHz
Gain 10±1dBi
VSWR ≤3.0
Impedance 50 Ω
Polarization Omnidirectional
Cable RG1.13mm
Cable Length 120mm
Connector U.FL/IPEX/MHF
Lightning Protection DC Ground

High Gain 5G New Radio PCB Antenna Mechanical Specifications

Dimension 113x16mm
Weight Approx. 12g
Material PCB
Operation Temperature -40˚C ~ +85˚C
Storage Temperature -40˚C ~ +80˚C
Color Green
Antenna Form Omni Dipole
Mounting Sticker/Connector
Safety Emission and other RoHS Compliant
Applications Public Safety/LMR/P25/TETRA, ISM/SCADA/Utilities, RFID, Wifi, GPS, GNSS, IoT/NB-IoT/LoRa/2G/3G/4G, GSM/GPRS/LTE/5G/6G

PCB Antenna Features

3M type or other adhesive sticker mount Antenna - C&T RF Antennas Inc
3M type or other adhesive sticker mount Antenna – C&T RF Antennas Inc



Well soldered on PCB board antenna manufacturer - C&T RF Antennas Inc
Well soldered on PCB board antenna manufacturer – C&T RF Antennas Inc



RG cable with low loss antenna extension antenna extender - C&T RF Antennas Inc
RG cable with low loss antenna extension antenna extender – C&T RF Antennas Inc



IPEX Antenna UFL Antenna MHF Antenna connector or Antenna with opening end - C&T RF Antennas Inc
IPEX Antenna UFL Antenna MHF Antenna connector or Antenna with opening end – C&T RF Antennas Inc
